Atomizer probe options
Standard tip up to 30 mL/min; flat tip up to 50 mL/min; radial spray; 35-degree upward spray; full-wave tip. Each geometry provides a different spray pattern.
Ultrasonic spray generation
QA40 Ultrasonic Atomizer
Controlled, low-velocity atomization for precise liquid delivery, with a choice of spray patterns and programmable continuous or pulsed output.
PRODUCT OVERVIEW
Precise delivery.
Gentle ultrasonic spray.
Ultrasonic energy creates a gentle spray that can be directed at a defined target area. The low spray velocity limits overspray and helps reduce material loss. Different nozzle geometries suit different applications, vessel shapes and spray coverage requirements.
Water produces an average droplet diameter of 50 µm. Liquid compatibility depends on formulation: the stated limits are less than 30% solids and viscosity below 50 cP. The liquid delivery arrangement can use a low-pressure metering pump or gravity feed.
The base system includes the generator and converter, cables and wrench set. The atomizing probe is a separate component, with standard, flat, radial, upward-spray and full-wave geometries available.
CAPABILITIES
Features
- Gentle ultrasonic spray with low forward velocity
- Continuous output or programmable on/off pulses
- Multiple probe geometries for directed spray coverage
- Average water droplet diameter of 50 µm
- Programmable timing up to 10 hours
APPLICATION FIT
Where it works
- Precision liquid application
- Low-velocity spray generation
- Controlled atomization with reduced overspray
Droplet size and flow depend on the liquid and probe geometry.
TECHNICAL DETAILS
Specifications
- Average droplet size
- 50 µm with water
- Liquid viscosity
- Below 50 cP
- Solids concentration
- Below 30%
- Timer
- Up to 10 hours
- Pulse on/off interval
- 1 second to 1 minute
- Generator (W × L × H)
- 8 × 13.75 × 5.75 in
- Electrical supply
- 110 V, 50/60 Hz; 220 V configuration also available
- System components
- Generator, converter, power and converter cables, wrench set
- Atomizing probe
- Separate component; application dependent
PARTS & ACCESSORIES
Available components
GLEN MILLS APPLICATION SUPPORT
Discuss your sample and process.
Talk with our team about QA40 Ultrasonic Atomizer, sample volumes and available configurations.
